DTC P0730: Gear Error Without Input Speed: Notes

WARNING: This page is about a different variant/trim than selected.
Fig 1: DTC P0730: Gear Error Without Input Speed Circuit Diagram
G02779534Courtesy of ISUZU MOTOR CO.
