Removal & Installation: Starter: Installation

1. Install starter assembly (4).
2. Install mounting bolts and tighten bolts (3). See TORQUE SPECIFICATIONS .
3. Reconnect the connectors to terminals "50" (2) and tighten terminals "30" (1). See Fig 1.
4. Install exhaust front left pipe (2) and tighten bolts and nuts. See TORQUE SPECIFICATIONS .
5. Connect two heated O2 Sensor Connector (1). See Figure.

Fig 1: Reconnecting Connectors To Terminals

Courtesy of ISUZU MOTOR CO.
