Inspection and Repair: Notes

  1. Use a internal micrometer to measure the diameter valve guide.

    Valve stem play

    1. Intake:  0.03 to 0.057 mm (0.0012 to 0.0022 in)
    2. Exhaust:  0.04 to 0.067 mm (0.0016 to 0.0026 in)
    Fig 1: Measuring Diameter Valve Guide
    G02779198Courtesy of ISUZU MOTOR CO.
