Adjustment Specifications
NOTE:
For carburetor electrical component testing, see I - CARB SYS/COMP TESTS article in this section.
I-MARK CARBURETOR ADJUSTMENT SPECIFICATIONS
| Component | In. (mm) |
|---|---|
| Float Drop | 1.74 (44.1) |
| Float Level | 0.59 (14.9) |
| Choke Breaker | 0.057 (1.44) |
| Choke Unloader | 0.071 (1.80) |
| Choke Valve | 0.08-0.09 (1.99-2.39) |
| Secondary Touch Angle | 0.22-0.26 (5.7-6.7) |
