Tune-Up - V8: Distributor
| Breaker Point Ignition | ||
| Point Gap | ||
| 345" Heavy Duty | Used.016", New.019" | |
| All Others | .016" | |
| Cam Angle | ||
| 304" Heavy Duty | 31-34° | |
| 400" | 29-31° | |
| All Others | 28-32° | |
| Breaker Arm Spring Tension | 17-21 ozs. | |
| Condenser Capacity | ||
| 400" | .18-.23 mfd. | |
| All Others | .21-.25 mfd. | |
| Electronic Ignition | ||
| Air Gap | .014" ±.002" | |
| Cam Angle (Not Adjustable) | 28-30° | |
