Exploded View

Courtesy of NISSAN NORTH AMERICA, INC.

1.	Quarter window glass	2.	Primer	3.	Adhesive
4.	Body side outer	5.	Quarter window glass molding	D.	29.5 mm (1.16 in)
E.	7.0 mm (0.28 in)	F.	12 mm (0.47 in)	G.	20 mm (0.79 in)
:	Clip
