Work Procedure
- Perform action test to verify the customer's concern.
- Perform action test and check the system operation after system diagnosis.
WARNING:
Be careful of traffic conditions and safety around the vehicle when performing road test.
CAUTION:
- Fully understand the following items well before the road test;
- System description for DAA: Refer to System Description .
- Handling precaution: Refer to Precautions for Driver Attention Alert .
- CHECK DAA SYSTEM SETTING
- Start the engine.
- After starting the engine wait for 30 seconds or more.
- Check that the DAA system setting can be enabled/disabled on the information display.
- Turn OFF the ignition switch and wait for 5 seconds or more.
- Check that the previous setting is saved when the engine starts again.
GO TO 2.
- ACTION TEST FOR DAA
- Enable the setting of the DAA system on the information display.
- Check the DAA operation according to the following table.
Vehicle condition/ Driver's operation
Display on combination meter
DAA OFF
--
DAA ON
INSPECTION END
