Chassis Control Module Connector End View (E22)
Connector Types: TH24FW-NH
| Terminal No. | Color of Wire | Signal Name (Specification) |
|---|---|---|
| 3 | R | CAN-L |
| 4 | L | CAN-H |
| 5 | V | DRIVE MODE SELECT SW (UP) |
| 6 | Y | DRIVE MODE SELECT SW (DOWN) |
| 7 | W | CHASSIS COMMUNICATION-L |
| 8 | W | CHASSIS COMMUNICATION-L |
| 10 | G | IGNITION POWER SUPPLY |
| 11 | L | CHASSIS COMMUNICATION-H |
| 12 | B | GROUND |
| 19 | BR | CHASSIS COMMUNICATION-H |
