Removal and Installation: Removal
CAUTION:
Always perform the camera calibration after the replacement, removal and installation of front camera unit. Refer to Description .
- Turn ignition switch OFF.
- Remove light & rain sensor cover. Refer to Removal and Installation .
- Push front camera unit
backwards using the remover tool (A) and disengage the catch hook from bracket as shown below .
CAUTION: The lens of the front camera unit must not be touched. Otherwise dirt cause the front camera unit to malfunction. - Disconnect front camera unit connector.
- Remove front camera unit.
