Removal and Installation: Removal

  1. Remove front door finisher. Refer to Removal and Installation .
  2. Remove power window main switch mounting screws SYMBOL , and then remove power window main switch SYMBOL from front door finisher SYMBOL .
    GNSJMKIB1738Z-738Courtesy of NISSAN NORTH AMERICA, INC.
