Distance Sensor (ICC Sensor) Alignment: Preparation

1. Adjust all tire pressure to the specified value.
2. Empty the vehicle. (Remove any luggage from the passenger compartment, luggage room, etc.)
3. Shift the selector lever to "P" position, and release the parking brake.
4. Fully fill the fuel tank, and then check that the coolant and oils are filled up to correct level.
5. Clean the distance sensor (ICC sensor) area of the front bumper grille.

   Courtesy of NISSAN NORTH AMERICA, INC.

Refer to Vehicle Set Up .
