Exploded View

WARNING: This page is about a different car, the 2018 Infiniti Q60. However, it is still accessible from the selected car via links, so may be relevant.
GNSJMLIA4338Z-338Courtesy of NISSAN NORTH AMERICA, INC.

SYMBOL

Optical sensor

SYMBOL

Front speaker grille

SYMBOL

: Pawl
