Park/Neutral Position Switch
>>
Exploded View
Exploded View
Fig 1: Exploded View Of Park/Neutral Position Switch
Courtesy of NISSAN NORTH AMERICA, INC.
Refer to "
COMPONENTS
" for symbols not described on the above.
