Periodic Maintenance
>>
Spark Plug
>>
Exploded View
Exploded View
Fig 1: Exploded View Of Spark Plug With Torque Specifications
Courtesy of NISSAN NORTH AMERICA, INC.
Refer to "
COMPONENTS
" for symbols in the figure.
