System Description
>>
Shift Mechanism
>>
Cross-Sectional View
>>
2WD Models
2WD Models
Fig 1: Cross-Sectional View Of Shift Mechanism (2WD Models)
Courtesy of NISSAN NORTH AMERICA, INC.
Courtesy of NISSAN NORTH AMERICA, INC.
