Low Battery Charge Warning Lamp
WARNING: This page is about a different car, the 2011 Nissan Leaf. However, it is still accessible from the selected car via links, so may be relevant.
The low battery charge warning lamp turns ON when the Li-ion battery remaining energy is lowered. When VCM detects that Li-ion battery remaining energy is approximately 4kWh or less, VCM transmits a low battery charge warning lamp request signal to the combination meter via CAN communication.
The low battery charge warning lamp operates as per the following.
LOW BATTERY CHARGE WARNING LAMP CONDITION CHART
| Condition | Illumination status |
|---|---|
| When Li-ion battery remaining energy is Approx. 4kWh or less. | ON |
| When Li-ion battery remaining energy recovers to 4.5 kWh or more while warning lamp is illuminating | ON => OFF |
| Except above | OFF |
