Infiniti
>>
2012
>>
G37 Base, 2D Convertible
>>
Repair and Diagnosis
>>
Engine Mechanical
>>
Engine Mechanical (Convertible)
>>
Periodic Maintenance
>>
Spark Plug
>>
Exploded View
Exploded View
Fig 1: Exploded View Of Spark Plug With Torque Specifications
Courtesy of NISSAN NORTH AMERICA, INC.
Refer to "
COMPONENTS
" for symbols in the figure.
