Power Limitation Indicator Lamp
WARNING: This page is about a different car, the 2011 Nissan Leaf. However, it is still accessible from the selected car via links, so may be relevant.
The output limit indicator turns on when the vehicle output is limited. When the vehicle output is limited, VCM sends an output limit indicator ON request signal to the combination meter via CAN communication.
The power limitation indicator lamp operates as per the following.
POWER LIMITATION INDICATOR LAMP CONDITION CHART
| Condition | Illumination status |
|---|---|
| 2 seconds after POWER ON | ON (bulb check) |
| When vehicle power is lowered | ON |
| Except above | OFF |
