With Continuous Damping Control

Fig 1: Exploded View Of Rear Shock Absorber With Torque Specifications (With Continuous Damping Control)
G08215004Courtesy of NISSAN NORTH AMERICA, INC.

Refer to "COMPONENTS " for symbols in the figure.
