WITH ELECTRIC MOTOR : Exploded View
WITH ELECTRIC MOTOR : Exploded View
Fig 1: Exploded View Of Electric Motor With Torque Specification
Courtesy of NISSAN MOTOR CO., U.S.A.
Refer to "
COMPONENTS
" for symbols in the figure.
