Oil Channel

Fig 1: Exploded View Of Oil Channel Components (VQ35DE Models For 2WD)
G05213507Courtesy of NISSAN MOTOR CO., U.S.A.
Fig 2: Exploded View Of Oil Channel Components (VK45DE Models For 2WD)
G05213508Courtesy of NISSAN MOTOR CO., U.S.A.
Fig 3: Exploded View Of Oil Channel Components (AWD Models)
G00469418Courtesy of NISSAN MOTOR CO., U.S.A.
