Component Layout

WARNING: This page is about a different car, the 2008 Infiniti FX45 and 2008 Infiniti FX35. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Refrigerant System Component Layout
G05221676Courtesy of NISSAN MOTOR CO., U.S.A.
