Exploded View

Fig 1: Exploded View Of Front Drive Shaft & Drive Chain Replacement Components With Torque Specifications
G05727228Courtesy of NISSAN MOTOR CO., U.S.A.

Refer to COMPONENTS for symbols not described above.
