Entry Operation

WARNING: This page is about a different car, the 2006 Infiniti QX56. However, it is still accessible from the selected car via links, so may be relevant.

When the front seat LH is in the exiting position, the following operation moves the seat to the previous position before the exiting operation.

Fig 1: Front Seat Entry Operation Flow Chart
G04135514Courtesy of NISSAN MOTOR CO., U.S.A.
