Automatic Drive Positioner: Schematic

Fig 1: CAN Communication Unit Schematic Diagram (1 Of 2)

Courtesy of NISSAN MOTOR CO., U.S.A.

Fig 2: CAN Communication Unit Schematic Diagram (2 Of 2)

Courtesy of NISSAN MOTOR CO., U.S.A.
