Removal and Installation of Intelligent Key Unit: Removal

  1. Remove the instrument lower driver panel. Refer to "REMOVAL AND INSTALLATION ".
  2. Disconnect the Intelligent Key unit connector, remove the screw and Intelligent Key unit.
    Fig 1: Identifying Instrument Lower Driver Panel
    G04077093Courtesy of NISSAN MOTOR CO., U.S.A.
