Removal and Installation: Installation

  1. Apply ATF or petroleum jelly to new O-ring.
    Fig 1: Installing Transfer Motor
    G02248676Courtesy of NISSAN MOTOR CO., U.S.A.
    NOTE: Do not reuse O-ring.
  2. Align width across flat-notch with oil pump groove, and install transfer motor.
  3. Tighten bolts.

    Transfer motor bolts :45 N.m (4.6 kg-m, 33 ft-lb)

  4. Install breather pipe to transfer motor.
  5. Connect transfer motor harness connector.
