Repair and Diagnosis
>>
Engine Mechanical
>>
Exhaust System
>>
Dual Mode Muffler
>>
Removal And Installation
>>
Notes
Removal And Installation: Notes
Fig 1: Identifying Connector Terminal
Courtesy of NISSAN MOTOR CO., U.S.A.
NOTE:
Exhaust control valve is provided in center muffler and not permitted to disassemble.
Courtesy of NISSAN MOTOR CO., U.S.A.
