Trouble Diagnosis Chart by Symptom
Always check the "Work Flow" before troubleshooting. Refer to
Work Flow
.
Before carrying out the inspection on the following table, perform the preliminary check. Refer to
Preliminary Check
.
Fig 1: Trouble Diagnosis Chart By Symptom (1 Of 2)
Courtesy of NISSAN MOTOR CO., U.S.A.
Fig 2: Trouble Diagnosis Chart By Symptom (2 Of 2)
Courtesy of NISSAN MOTOR CO., U.S.A.
