Standard And Limit
WARNING: This page is about a different car, the 2004 Infiniti FX35 and 2003 Infiniti FX35. However, it is still accessible from the selected car via links, so may be relevant.
General Specifications
| Cylinder arrangement |
V-6 |
| Displacement cm3
(cu in) |
3,498 (213.45) |
| Bore and stroke mm (in) |
95.5 x 81.4 (3.76 x 3.205) |
| Valve arrangement |
DOHC |
| Firing order |
1-2-3-4-5-6 |
| Number of piston rings |
Compression |
2 |
| Oil |
1 |
| Number of main bearings |
4 |
| Compression ratio |
10.3 |
| Compression pressure kPa (kg/cm2
, psi)/300 rpm |
Standard |
1,275 (13.0,185) |
| Minimum |
981 (10.0,142) |
| Differential limit between cylinders |
98 (1.0,14) |
| Cylinder number |
|
| Valve timing (Intake valve timing control - "OFF") |
|
| Unit: degree |
| a |
b |
c |
d |
e |
f |
| 240 |
238 |
-6 |
64 |
8 |
52 |
