Home >> Infiniti >> 2004 >> FX35 AWD >> Repair and Diagnosis >> Steering >> Power Steering System >> Power Steering Oil Pump >> Disassembly And Assembly (VK45DE Models) >> Notes

Disassembly And Assembly (VK45DE Models): Notes

Fig 1: Displaying Oil Pump Components (VK45DE Models)

G00725733

Courtesy of NISSAN MOTOR CO., U.S.A.
