Standard And Limit
WARNING: This page is about a different car, the 2004 Infiniti FX45 and 2003 Infiniti FX45. However, it is still accessible from the selected car via links, so may be relevant.
General Specifications
| Cylinder arrangement |
V-8 |
| Displacement cm3
(cu in) |
4,494 (274.22) |
| Bore and stroke mm (in) |
93 x 82.7 (3.66 x 3.256) |
| Valve arrangement |
DOHC |
| Firing order |
1-8-7-3-6-5-4-2 |
| Number of piston rings |
Compression |
2 |
| Oil |
1 |
| Number of main bearings |
5 |
| Compression ratio |
10.5 |
| Compression pressure kPa (kg/cm2
, psi)/300 rpm |
Standard |
1,320 (13.5, 191) |
| Minimum |
1,130 (11.5, 164) |
| Differential limit between cylinders |
98 (1.0, 14) |
| Cylinder number |
|
| Valve timing |
|
| Unit: degree |
| a |
b |
c |
d |
e |
f |
| 228 |
240 |
0 |
60 |
0 |
48 |
