DTC P1111 & P1136 IVT Control Solenoid Valve
>>
CONSULT-II Reference Value in Data Monitor Mode
CONSULT-II Reference Value in Data Monitor Mode
Specification data are reference values.
Fig 1: Identifying DTC P1111 & P1136 Specifications (CONSULT-II)
Courtesy of NISSAN MOTOR CO., U.S.A.
Courtesy of NISSAN MOTOR CO., U.S.A.
