Removal and Installation: Notes
Fig 1: Exploded View Of Driver Side Power Seat
Courtesy of NISSAN MOTOR CO., U.S.A.
Fig 2: Exploded View Of Passenger Side Power Seat
Courtesy of NISSAN MOTOR CO., U.S.A.
Courtesy of NISSAN MOTOR CO., U.S.A.
Courtesy of NISSAN MOTOR CO., U.S.A.
