Front Wheel Turning Angle

  1. Set wheels in straight-ahead position. Then, move vehicle forward until front wheels rest on turning radius gauge properly.
  2. Rotate steering wheel all the way right and left; measure turning angle.

    Wheel turning angle (Full turn):

    Refer to  SDS  .

    Fig 1: Setting Wheels In Straight-Ahead Position
    G02842576
