Home >> Hyundai >> 2025 >> Kona Limited, 4WD >> Repair and Diagnosis >> Engine Performance >> System >> Engine Control System Diagnosis - 1.6 (2 Of 2) >> DTC P2251-00: O2 Sensor Reference Ground Circuit/Open (Bank 1 Sensor 1) >> Troubleshooting >> Diagnostic Flowchart
