Assist Power Window Switch

  1. Disconnect the negative (-) battery terminal.
  2. Remove the front door trim. (Refer to Body - "FRONT DOOR TRIM ")
  3. Remove the power window switch assembly (A) after loosening the mounting screws.
    G16149120Courtesy of HYUNDAI MOTOR AMERICA
