Repair Procedures: Inspection

  1. Visually check the belt for excessive wear, frayed cords etc.

    If any defect has been found, replace the drive belt.

    NOTE:
    • Cracks on the rib side of a belt are considered acceptable. If the belt has chunks missing from the ribs, it should be replaced.
    G15471472Courtesy of HYUNDAI MOTOR AMERICA
