| 13 |
PUMP MOTOR GROUND |
137 (RUSH) |
10 |
- |
| 38 |
GROUND |
40 |
10 |
- |
| 1 |
POS. BATTERY 2. (MOTOR) |
137 (RUSH) |
10 |
- |
| 25 |
POS. BATTERY 1. (SOLENOID) |
40 |
10 |
- |
| 29 |
IGN1 (+) |
50 mA |
60 |
- |
| 34 |
SENSOR FRONT LEFT POWER |
30 mA |
250 |
- |
| 18 |
SENSOR FRONT RIGHT POWER |
30 mA |
250 |
- |
| 33 |
SENSOR REAR LEFT POWER |
30 mA |
250 |
- |
| 19 |
SENSOR REAR RIGHT POWER |
30 mA |
250 |
- |
| 21 |
SENSOR FRONT LEFT SIGNAL |
16.8 mA |
250 |
- |
| 31 |
SENSOR FRONT RIGHT SIGNAL |
16.8 mA |
250 |
- |
| 20 |
SENSOR REAR LEFT SIGNAL |
16.8 mA |
250 |
- |
| 32 |
SENSOR REAR RIGHT SIGNAL |
16.8 mA |
250 |
- |
| 23 |
ESC OFF SWITCH |
10mA |
250 |
- |
| 14 |
C-CAN High |
30 mA |
250 |
- |
| 2 |
C-CAN Low |
30 mA |
250 |
- |
| 22 |
L-CAN High |
30 mA |
250 |
- |
| 35 |
L-CAN Low |
30 mA |
250 |
- |
| 16 |
BRAKE LIGHT SWITCH |
10 mA |
250 |
- |
| 37 |
CLUTCH SWITCH |
10 mA |
250 |
- |
| 30 |
DBC SWITCH |
10 mA |
250 |
- |
| 28 |
SENSOR REAR RIGHT OUTPUT |
16 mA |
250 |
- |
| 17 |
SENSOR FRONT RIGHT OUTPUT |
16 mA |
250 |
- |
