Repair Procedures: Replacement

WARNING: This page is about a different car, the 2017 Hyundai Elantra. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the front door trim.

    (Refer to Front Door - "FRONT DOOR TRIM ")

  2. After loosening the mounting screws, remove the front door inside handle (A).
    Fig 1: Locating Front Door Inside Handle
    G12022560Courtesy of HYUNDAI MOTOR AMERICA
  3. To install, reverse the removal procedure.
    NOTE:
    • Make sure the door locks/unlocks and opens/closes properly.
    • Replace any damaged clips (or pin-type retainers).
