Starting System: Troubleshooting

WARNING: This page is about a different variant/trim than selected.

NOTE:

The Battery must be in good condition and fully charged for this Troubleshooting.

Fig 1: Battery Charging System Flow Chart

Courtesy of HYUNDAI MOTOR AMERICA
