Repair Procedures: Inspection

  1. Turn Ignition Switch OFF and disconnect the negative (-) battery cable.
  2. Remove the console upper cover. (Proceed to Body - "FLOOR CONSOLE ")
  3. Disconnect the connector (A).
    Fig 1: Removing Console Upper Cover
    G11644768Courtesy of HYUNDAI MOTOR AMERICA
  4. Check the continuity between the switch terminals as the DBC switch is engaged.
    Fig 2: Checking Continuity Between DBC Switch Terminals
    G11644769Courtesy of HYUNDAI MOTOR AMERICA
