Rear Power Window Switch

  1. Disconnect the negative (-) battery terminal.
  2. Remove the rear door trim.

    (Proceed to Body - "REAR DOOR TRIM ")

  3. Remove the power window switch assembly (A) after loosening the mounting screws.
Fig 1: Loosening Power Window Switch Assembly Mounting Screws
G11670063Courtesy of HYUNDAI MOTOR AMERICA
