Hub Bolt Removal

WARNING: This page is about a different car, the 2015 Mitsubishi Mirage. However, it is still accessible from the selected car via links, so may be relevant.

Use special tool hub bolt remover (MB991618) to remove the hub bolt.

Fig 1: Removing Hub Bolt Using Tool
G09631560Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
