Repair Procedures: Removal: Notes

Disconnect the negative (-) battery terminal.
Rotate the steering wheel about 90° clockwise or counter-clockwise to remove the screws and airbag module lock pins.

Fig 1: Rotating Steering Wheel 90%
Courtesy of HYUNDAI MOTOR AMERICA

Fig 2: Removing Screws And Airbag Module Lock Pins
Courtesy of HYUNDAI MOTOR AMERICA
Separate the driver side airbag module (A) by pushing three lock pins.

Fig 3: Pushing Driver Side Airbag Module Lock Pins
Courtesy of HYUNDAI MOTOR AMERICA

Fig 4: Driver Side Airbag Module
Courtesy of HYUNDAI MOTOR AMERICA
Remove to remove the steering wheel remote control switch the screws.

Fig 5: Steering Wheel Remote Control Switch Screws
Courtesy of HYUNDAI MOTOR AMERICA

Fig 6: Steering Wheel Remote Control Switch
Courtesy of HYUNDAI MOTOR AMERICA
Disconnect the steering wheel remote control switch connector (A) after loosening screws.
