Repair Procedures: Installation

NOTE:

When replacing a clutch housing, the wiring bracket should be installed in accordance with the clutch housing type.
[A-Type Clutch Housing]

Fig 1: Identifying A-Type Clutch Housing & Wiring Bracket (1 Of 2)
Courtesy of HYUNDAI MOTOR AMERICA

Fig 2: Identifying A-Type Clutch Housing & Wiring Bracket (2 Of 2)
Courtesy of HYUNDAI MOTOR AMERICA

[B-Type Clutch Housing]

Fig 3: Identifying B-Type Clutch Housing & Wiring Bracket (1 Of 2)
Courtesy of HYUNDAI MOTOR AMERICA

Fig 4: Identifying B-Type Clutch Housing & Wiring Bracket (2 Of 2)
Courtesy of HYUNDAI MOTOR AMERICA

Install in the reverse order of removal.

CAUTION:

Adding Manual transaxle fluid. (Refer to MANUAL TRANSAXLE FLUID - NON-TURBO )
