Removal And Installation: Notes
WARNING: This page is about a different car, the 2014 Mitsubishi Mirage. However, it is still accessible from the selected car via links, so may be relevant.
CAUTION:
- Before removing the steering wheel and air bag module assembly, refer to SERVICE PRECAUTIONS and Air Bag Module and Clock Spring. Also, put the front wheels in straight-ahead position. Failure to do so may damage the SRS clock spring and render the SRS air bag inoperative, which results serious driver injury.
- *: Indicates parts which should be temporarily tightened, and then fully tightened with the vehicle on the ground in an unladen condition.
Required Special Tools:
- MB991113: Steering linkage puller
