Components and Components Location: Components
WARNING: This page is about a different variant/trim than selected.
Courtesy of HYUNDAI MOTOR AMERICA
| 1. Union bolt |
7. Bleeder screw |
| 2. Gasket |
8. Release cylinder |
| 3. Tube joint |
9. Return spring |
| 4. Clutch |
10. Piston |
| 5. Valve plate |
11. Boot |
| 6. Valve spring |
12. Push rod |
