Repair Procedures: Inspection: Rotor
WARNING: This page is about a different car, the 2014 Hyundai Santa Fe Sport and 2013 Hyundai Santa Fe Sport. However, it is still accessible from the selected car via links, so may be relevant.
- Check that there is continuity between the slip rings (C).
- Check that there is no continuity between the slip rings and the rotor (B) or rotor shaft (A).
- If the rotor fails either continuity check, replace the alternator.
