Components and Components Location: Components

WARNING: This page is about a different car, the 2014 Hyundai Santa Fe Sport and 2013 Hyundai Santa Fe Sport. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Dynamic Damper Components Location
G09367923Courtesy of HYUNDAI MOTOR AMERICA
